Long Life Rubber Vulcanizing Press Machine frame type / four column type

Name: Long Life Rubber Vulcanizing Press Machine frame type four column type
Brand: Fulund
Price: 1 USD

Quality Long Life Rubber Vulcanizing Press Machine frame type / four column type for sale

Brand Name : Fulund

Model Number : FLD-V70T

Certification : CE

Place of Origin : CHINA

MOQ : 1

Price : USD

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 100PCS/MONTH

Delivery Time : 7days

Packaging Details : WOODEN CASE

Machine Type : Plate Vulcanizing Press, Vulcanizing Press

Dimension(L*W*H) : 1600*1200*1600MM

Operating type : Automatic

Voltage : 380V

Weight : 1100kg

Power (kW) : 13

Maximum stroke : 240mm

Maximum width : 450*450mm

Keyword 1 : rubber press

Keyword 2 : vulcanizing press machine

Keyword 3 : rubber vulcanizing press

Contact Now

Long life Rubber Vulcanizing Press Machine with overseal service

Fulund has a long history since its establishment in 1999. Due to the needs of development, the original brand (TYL) expanded the new brand Fulund in 2022 . Fulund has customers all over the world,such as international brands shoe manufacturer.

Fulund mainly produces: Hot label machine, foam cutting machine, insole hot stamping machine, shoe tongue transfer hot stamping machine, insole heat transfer machine, insole cutting and transfer integrated machine, insole printing machine, silk screen printing machine, embossing machine, soft rubber equipment , vacuum vulcanizing machine, silicone labeling machine, glue dispensing machine, etc.

The structure of the vulcanizing machine has a frame type and a four-column type. The heating forms are divided into three heating modes: electric heating, steam heating, and thermal oil heating. With automatic vulcanizing machine, automatic pressure compensation, automatic alarm device

The vulcanizer hydraulic system produced by our company has a scientific design, overall rigidity, low noise, and convenient operation. It can be controlled sequentially according to the pressure, time, speed and temperature required for different products into the PLC. Secondary exhaust to improve product quality and product yield

Technical parameters:

Model No.	FLD-V70T
Machine size	160012001600mm
Weight	1100kg
Power	13kw
Hot plate specifications	400*400mm
Temperature range	Normal temperature -350℃
Hot plate spacing	200mm
Way to heat up	Imported heating tube
Mold opening method	Automatic mold release
System pressure	18MPa
Main column diameter	210mm
Clamping stroke	220mm
Work level	Upper and lower layers
Motor power	3.75kw
Greatest pressure	70 tons
Machine structure	Four-column/single-head model
Power specifications	380V/50HZ

Application scope:

Drop plastic production of PVC trademark and soft rubber label

PVC cartoon and handicraft drop plastic production

Production of PVC shoes, bags and other clothing accessories

Long Life Rubber Vulcanizing Press Machine frame type / four column type

Packing&Shipping

Packing Detail:

 ☂ Each Vulcanizing press machine with plastic film package first, then placed in a wooden case, wooden case with a foam
 filling.

 ✈ We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers
 and ship them abroad.

 Delivery Detail :

 ☀ Shipped in 30 days after payment.
